30KW隧道风机/SDS-7.1隧道射流风机
详细信息
| | 品牌：华博 | | 型号：SDS-7.1 | | 材质：Q235 | |
| | 风机压力：低压风机 | | 性能：低噪音风机 | | 轴功率：27 kw | |
| | 叶片数：/ | | 重量：/ kg | | 涡轮头性质：/ | |
| | 转速：2900 | | 配套电机功率：30 kw | | 适用范围：隧道通风 | |
SDS隧道射流风机
一、特性及应用
SDS遂道射流风机采用先进技术工艺所研制开发的新产品，其外壳由美国进口专用机床旋压翻边成形，叶轮段内壁经金加工，既保证机壳的同轴度和强度，又保证叶片径向间隙，表面涂装处理，外形美观及防腐性能优良。内置鼠笼全封闭式射流通风机配套电机，并设法兰安装盘，电机绝缘等级为H级，防腐等级为IP55。其风量大小可以通过改变叶片数和叶片角度来满足要求。对于噪声要求高场合，可增加消声器来减少其噪声。
遂道式通风机分单向射流风机SDS和双向射流风机SDS(R)二种通风形式，SDS(R)型遂道射流风机有电子式和机械式二种切换方式，可在30秒钟内正反转切换到风机额定转速。
该风机各项性能指标及耐腐蚀、可靠性、经济性等技术、质量要求和经济指标完全能适应水利大坝工程、公路、铁路、地铁等隧道的实际使用。
|
风机型号
|
风量(m3/s)
|
出口风速
(m/s)
|
电机
|
不带消声器
|
带消声器
|
|
机座号
|
功率
(kW)
|
风机功率
(kW)
|
推力
(N)
|
声压
dB(A)
|
重量
(kg)
|
1D
|
2D
|
|
推力
(N)
|
声压
dB(A)
|
声功率
(kW）
|
重量
(kg)
|
推力
(N)
|
声压
dB(A)
|
重量
(kg)
|
|
SDS-6.3-2P-4-18°
|
8.1
|
26.0
|
132
|
7.5
|
6.8
|
247
|
78
|
135
|
244
|
68
|
96
|
245
|
239
|
64
|
322
|
|
SDS-6.3-2P-4-21°
|
9.0
|
28.9
|
160
|
11
|
8.4
|
305
|
79
|
182
|
302
|
69
|
97
|
292
|
296
|
65
|
369
|
|
SDS-6.3-2P-4-24°
|
9.9
|
31.8
|
160
|
11
|
10.1
|
369
|
80
|
182
|
365
|
70
|
98
|
292
|
358
|
66
|
369
|
|
SDS-6.3-2P-4-27°
|
10.8
|
34.7
|
160
|
15
|
12.0
|
439
|
81
|
190
|
435
|
71
|
99
|
300
|
426
|
67
|
377
|
|
SDS-6.3-2P-4-30°
|
11.7
|
37.5
|
160
|
15
|
14.1
|
513
|
82
|
190
|
508
|
72
|
100
|
300
|
498
|
68
|
377
|
|
SDS-6.3-2P-4-33°
|
12.7
|
40.6
|
160
|
18.5
|
17.2
|
602
|
84
|
212
|
596
|
75
|
102
|
322
|
584
|
70
|
399
|
|
SDS-7.1-2P-6-18°
|
12.7
|
32.0
|
160
|
15
|
13.3
|
475
|
81
|
208
|
470
|
71
|
99
|
338
|
461
|
67
|
433
|
|
SDS-7.1-2P-6-21°
|
14.0
|
35.4
|
160
|
18.5
|
16.9
|
581
|
82
|
230
|
575
|
72
|
100
|
360
|
564
|
68
|
455
|
|
SDS-7.1-2P-6-24°
|
15.0
|
37.9
|
180
|
22
|
20.1
|
666
|
84
|
263
|
659
|
72
|
100
|
393
|
646
|
69
|
488
|
|
SDS-7.1-2P-6-27°
|
16.0
|
40.4
|
200
|
30
|
22.9
|
757
|
85
|
323
|
749
|
73
|
101
|
453
|
734
|
71
|
548
|
|
SDS-7.1-2P-6-30°
|
17.0
|
42.9
|
200
|
30
|
25.8
|
853
|
86
|
323
|
845
|
75
|
103
|
453
|
828
|
72
|
548
|
|
SDS-7.1-2P-6-33°
|
18.0
|
45.5
|
200
|
37
|
30.0
|
960
|
87
|
338
|
950
|
77
|
105
|
468
|
931
|
73
|
563
|
|
SDS-8-4P-6-18°
|
9.3
|
18.6
|
112
|
4
|
3.1
|
204
|
66
|
138
|
202
|
56
|
84
|
310
|
198
|
52
|
435
|
|
SDS-8-4P-6-21°
|
10.6
|
21.0
|
132
|
5.5
|
4.2
|
260
|
68
|
163
|
257
|
58
|
86
|
335
|
252
|
54
|
460
|
|
SDS-8-4P-6-24°
|
11.8
|
23.5
|
132
|
7.5
|
5.5
|
325
|
69
|
176
|
322
|
59
|
87
|
348
|
315
|
55
|
473
|
|
SDS-8-4P-6-27°
|
12.6
|
25.0
|
132
|
7.5
|
6.6
|
368
|
70
|
176
|
364
|
60
|
88
|
348
|
357
|
55
|
473
|
|
SDS-8-4P-6-30°
|
13.3
|
26.5
|
160
|
11
|
7.7
|
413
|
71
|
218
|
409
|
62
|
90
|
390
|
401
|
57
|
515
|
|
SDS-8-4P-6-33°
|
14.1
|
28.0
|
160
|
11
|
9.4
|
461
|
72
|
218
|
457
|
63
|
91
|
390
|
448
|
58
|
515
|
|
SDS-9-4P-6-18°
|
13.0
|
20.5
|
132
|
7.5
|
5.4
|
313
|
70
|
232
|
310
|
60
|
88
|
414
|
304
|
56
|
569
|
|
SDS-9-4P-6-21°
|
14.6
|
22.9
|
160
|
11
|
7.1
|
391
|
71
|
274
|
387
|
62
|
90
|
456
|
379
|
58
|
611
|
|
SDS-9-4P-6-24°
|
16.1
|
25.3
|
160
|
11
|
9.0
|
477
|
72
|
274
|
472
|
63
|
91
|
456
|
463
|
59
|
611
|
|
SDS-9-4P-6-27°
|
16.7
|
26.2
|
160
|
11
|
9.9
|
511
|
73
|
274
|
506
|
64
|
92
|
456
|
496
|
60
|
611
|
|
SDS-9-4P-6-30°
|
18.8
|
29.5
|
160
|
15
|
13.1
|
641
|
75
|
295
|
634
|
65
|
93
|
477
|
620
|
61
|
632
|
|
SDS-9-4P-6-33°
|
20.1
|
31.6
|
180
|
18.5
|
16.9
|
744
|
76
|
333
|
736
|
67
|
94
|
515
|
722
|
63
|
670
|
|
SDS-10-4P-6-18°
|
17.7
|
22.5
|
160
|
11
|
9.8
|
466
|
72
|
306
|
461
|
63
|
95
|
518
|
452
|
60
|
703
|
|
SDS-10-4P-6-21°
|
19.6
|
25.0
|
160
|
15
|
11.7
|
575
|
73
|
327
|
569
|
64
|
91
|
539
|
558
|
61
|
724
|
|
SDS-10-4P-6-24°
|
21.2
|
27.0
|
160
|
15
|
13.9
|
670
|
75
|
327
|
664
|
66
|
92
|
539
|
650
|
63
|
724
|
|
SDS-10-4P-6-27°
|
23.2
|
29.5
|
180
|
1.5
|
17.1
|
800
|
77
|
365
|
792
|
67
|
94
|
577
|
776
|
64
|
762
|
|
SDS-10-4P-6-30°
|
24.3
|
31.0
|
180
|
22
|
21.2
|
884
|
78
|
373
|
875
|
69
|
95
|
585
|
857
|
65
|
770
|
|
SDS-10-4P-6-33°
|
26.9
|
34.2
|
200
|
30
|
27.5
|
1076
|
79
|
453
|
1065
|
70
|
97
|
665
|
1044
|
66
|
850
|
|
SDS-11.2-4P-6-18°
|
24.8
|
25.2
|
180
|
18.5
|
17.3
|
744
|
77
|
427
|
736
|
68
|
98
|
639
|
722
|
65
|
824
|
|
SDS-11.2-4P-6-21°
|
27.3
|
27.7
|
180
|
22
|
20.5
|
899
|
78
|
435
|
890
|
69
|
96
|
647
|
872
|
66
|
832
|
|
SDS-11.2-4P-6-24°
|
29.9
|
30.3
|
200
|
30
|
24.6
|
1075
|
80
|
515
|
1065
|
71
|
97
|
727
|
1043
|
68
|
912
|
|
SDS-11.2-4P-6-27°
|
32.3
|
32.8
|
225
|
37
|
30.3
|
1360
|
80
|
529
|
1247
|
71
|
99
|
741
|
1223
|
69
|
926
|
|
SDS-11.2-4P-6-30°
|
34.9
|
35.4
|
225
|
45
|
38.4
|
1468
|
81
|
565
|
1453
|
72
|
100
|
777
|
1424
|
69
|
962
|
|
SDS-11.2-4P-6-33°
|
37.4
|
38
|
250
|
55
|
46.2
|
1691
|
83
|
672
|
1674
|
73
|
101
|
884
|
1641
|
70
|
1069
|
|
SDS-12.5-4P-6-18°
|
35.0
|
28.5
|
225
|
37
|
29.8
|
1185
|
82
|
574
|
1173
|
72
|
100
|
852
|
1150
|
70
|
1137
|
|
SDS-12.5-4P-6-21°
|
38.3
|
31.2
|
225
|
37
|
34.5
|
1420
|
82
|
574
|
1406
|
73
|
101
|
852
|
1378
|
70
|
1137
|
|
SDS-12.5-4P-6-24°
|
41.6
|
33.9
|
225
|
45
|
41.2
|
1677
|
83
|
610
|
1660
|
74
|
102
|
888
|
1627
|
71
|
1173
|
|
SDS-12.5-4P-8-27°
|
45.2
|
36.8
|
250
|
55
|
50.8
|
1976
|
84
|
717
|
1956
|
76
|
104
|
995
|
1917
|
73
|
1280
|
|
SDS-12.5-4P-8-30°
|
48.5
|
39.5
|
280
|
75
|
66.4
|
2276
|
85
|
852
|
2254
|
77
|
105
|
1130
|
2208
|
74
|
1415
|
|
SDS-12.5-4P-8-33°
|
51.5
|
42.0
|
280
|
90
|
81.9
|
2574
|
86
|
957
|
2548
|
78
|
106
|
1235
|
2497
|
74
|
1520
|
|
SDS-12.5-6P-6-18°
|
23.1
|
18.8
|
160
|
11
|
8.4
|
516
|
69
|
437
|
510
|
60
|
88
|
715
|
500
|
57
|
1000
|
|
SDS-12.5-6P-6-21°
|
25.4
|
20.7
|
180
|
15
|
10.7
|
625
|
70
|
485
|
619
|
61
|
89
|
763
|
607
|
58
|
1048
|
|
SDS-12.5-6P-6-24°
|
27.6
|
22.5
|
180
|
15
|
12.3
|
739
|
71
|
485
|
731
|
63
|
91
|
763
|
717
|
60
|
1048
|
|
SDS-14-6P-8-27°
|
29.8
|
24.3
|
200
|
18.5
|
15.6
|
861
|
72
|
510
|
853
|
64
|
92
|
788
|
836
|
61
|
1073
|
|
SDS-14-6P-8-30°
|
32.2
|
26.2
|
200
|
22
|
18.9
|
1001
|
73
|
540
|
991
|
64
|
92
|
818
|
972
|
61
|
1103
|
|
SDS-14-6P-8-33°
|
34.5
|
28.1
|
225
|
30
|
23.7
|
1152
|
74
|
582
|
1140
|
66
|
94
|
860
|
1118
|
63
|
1145
|
|
SDS-14-6P-6-18°
|
33.6
|
21.8
|
200
|
18.5
|
16.5
|
870
|
73
|
656
|
861
|
64
|
92
|
947
|
844
|
61
|
1292
|
|
SDS-14-6P-6-21°
|
36.8
|
23.9
|
200
|
22
|
18.1
|
1045
|
74
|
686
|
1035
|
65
|
93
|
977
|
1014
|
62
|
1322
|
|
SDS-14-6P-6-24°
|
39.9
|
25.9
|
225
|
30
|
24.8
|
1228
|
75
|
758
|
1215
|
66
|
94
|
1019
|
1191
|
64
|
1364
|
|
SDS-14-6P-8-27°
|
43.1
|
28.0
|
250
|
37
|
30.2
|
1435
|
76
|
844
|
1420
|
68
|
96
|
1135
|
1392
|
65
|
1480
|
|
SDS-14-6P-8-30°
|
46.3
|
30.1
|
280
|
45
|
35.5
|
1658
|
77
|
972
|
1642
|
68
|
96
|
1263
|
1609
|
66
|
1608
|
|
SDS-14-6P-8-33°
|
49.6
|
32.2
|
280
|
55
|
45.7
|
1898
|
78
|
1031
|
1879
|
69
|
97
|
1322
|
1841
|
67
|
1667
|
|
SDS-14-8P-6-18°
|
25.4
|
16.5
|
160
|
7.5
|
6.1
|
498
|
64
|
581
|
493
|
55
|
83
|
872
|
483
|
52
|
1217
|
|
SDS-14-8P-6-21°
|
27.7
|
18.0
|
180
|
11
|
7.7
|
593
|
65
|
620
|
587
|
57
|
85
|
911
|
575
|
54
|
1256
|
|
SDS-14-8P-6-24°
|
30.0
|
19.5
|
200
|
15
|
9.9
|
696
|
66
|
686
|
689
|
58
|
86
|
977
|
675
|
55
|
1322
|
|
SDS-14-8P-8-27°
|
32.5
|
21.1
|
225
|
15
|
13.5
|
815
|
68
|
686
|
807
|
59
|
87
|
977
|
790
|
57
|
1322
|
|
SDS-14-8P-8-30°
|
34.6
|
22.5
|
225
|
18.5
|
15.1
|
926
|
68
|
702
|
917
|
59
|
87
|
993
|
899
|
57
|
1338
|
|
SDS-14-8P-8-33°
|
37.1
|
24.1
|
250
|
22
|
19.5
|
1063
|
69
|
728
|
1052
|
61
|
89
|
1019
|
1031
|
58
|
1364
|
|
SDS-16-6P-6-18°
|
47.2
|
23.5
|
225
|
30
|
24.1
|
1320
|
77
|
892
|
1307
|
68
|
96
|
1240
|
1281
|
66
|
1680
|
|
SDS-16-6P-6-21°
|
52.1
|
25.9
|
250
|
37
|
32.5
|
1603
|
78
|
1008
|
1587
|
69
|
97
|
1356
|
1556
|
67
|
1796
|
|
SDS-16-6P-6-24°
|
57.1
|
28.4
|
280
|
55
|
45.6
|
1928
|
80
|
1195
|
1909
|
71
|
99
|
1543
|
1870
|
68
|
1983
|
|
SDS-16-6P-6-27°
|
61.9
|
30.8
|
315
|
75
|
56.2
|
2268
|
81
|
1590
|
2245
|
73
|
101
|
1938
|
2200
|
70
|
2378
|
|
SDS-16-6P-8-30°
|
67.0
|
33.3
|
315
|
75
|
65.7
|
2651
|
82
|
1590
|
2624
|
73
|
101
|
1938
|
2572
|
71
|
2378
|
|
SDS-16-6P-8-33°
|
71.8
|
35.7
|
315
|
90
|
83.5
|
3046
|
83
|
1680
|
3016
|
75
|
103
|
2028
|
2956
|
72
|
2468
|
|
SDS-16-8P-6-18°
|
35.6
|
17.7
|
200
|
15
|
10.8
|
749
|
69
|
850
|
741
|
61
|
89
|
1198
|
727
|
58
|
1638
|
|
SDS-16-8P-6-21°
|
39.2
|
19.5
|
225
|
15
|
13.2
|
909
|
69
|
850
|
900
|
61
|
89
|
1198
|
882
|
58
|
1638
|
|
SDS-16-8P-6-24°
|
42.8
|
21.3
|
225
|
22
|
18.1
|
1084
|
71
|
892
|
1074
|
63
|
91
|
1240
|
1052
|
61
|
1680
|
|
SDS-16-8P-6-27°
|
46.6
|
23.2
|
250
|
30
|
24.2
|
1287
|
72
|
1005
|
1274
|
64
|
92
|
1353
|
1248
|
62
|
1793
|
|
SDS-16-8P-8-30°
|
50.3
|
25.0
|
280
|
37
|
32.5
|
1498
|
73
|
1120
|
1479
|
65
|
93
|
1468
|
1449
|
63
|
1908
|
|
SDS-16-8P-8-33°
|
53.9
|
26.8
|
280
|
45
|
34.6
|
1717
|
74
|
1192
|
1700
|
66
|
94
|
1540
|
1666
|
64
|
1980
|
